48203-0665 | Coleman Mach 13,500 BTU | Air Conditioner | Roughneck | Textured White

  • Buy 3 for $1,275.79 each and save 5%
  • BTUs: 13,500
  • Heat Pump: No
  • Power Saver: No
  • Condensate Pump: No
  • Volt rating: 115VAC, 60Hz, 1 Phase
  • Full-Load Cooling Amps: 13.1
  • Standard Running Watts: 1400
  • Weight: 79.5Lbs
  • Height: Standard  (13.8")

ROUGHNECK  AIR CONDITIOENR— IT’S TOUGH! NOW CHARGED WITH (ECO-FRIENDLY) R-410A.

When it comes to air conditioners, power and strength do not necessarily mean the same thing. But they do come in the same package with a Coleman®-Mach® Roughneck™ RV air conditioner.

The Roughneck™ gives you plenty of high-efficiency cooling power, but also has a lot of inner strength to handle rugged, off-road and heavy industrial vehicle applications.

It's specially equipped to handle the jarring and vibrations that come with the territory, whether you're in construction, the oil field or just taking the back roads to your favorite fishing hole.

  • At 1/3 hp, the fan motor in the Roughneck™ is the largest in the industry. It features a sealed shaft to protect against dust and cooling capacity loss.
  • Large evaporator and condenser coils have raised lance fins that enhance heat transfer. The copper tubing has been rifled inside to create turbulence in the  coolant, which also enhances the system's ability to dissipate heat.
  • The top and bottom of the compressor are secured to the air conditioner chassis, reducing the potential for damage when used in high-stress applications.
  • Start kit with start capacitors and relays is provided as standard equipment to allow the unit to start easier under high temperature and humidity conditions.
  • To prevent distortion of the angle of the blower wheel and ensure a free turning action, the motor is mounted directly to the bulkhead. This fixes the motor's  position in relation to the blower wheel and scroll.
  • Optional Heater Assembly can be added to provide a source of warm air.
  • Plastic drain pan eliminates corrosion.
  • Corrosion-resistant, stainless steel truss head screws secure the shroud.



More Information
Fit & Function GuaranteeNo
MSRP$1,843.69
Mfg Part #48203-0665

Documentation

Installation, Operation & MaintenanceDOWNLOAD

Specifications

HeightStandard (13.8")
Weight (lbs)79.5
BTUs13,500
Heat Strip BTUs5,600
Electrical Rating115 VAC, 60Hz, 1 Phase
Full-Load Cooling Amps13.1
Full-Load Heating Amps16
Standard Running Watts1,400
Running watts w/ heat strip1,800
Air Delivery CFM320
ColorTextured White
Heat PumpNo
Power SaverNo
Condensate PumpNo
Soft StartNo
Model Number Changes

This unit is a replacement for the following models:



48253-6665
48253C9665
48253-8765
48253A8765
48253B8765
48253B8765
48253C8665
48203-6665
48203C9665
48203-8765
48203A8765
48203B8765
48203B8765
48203C8665
48213-8765
48213-8765
48213A8765
48213A8765
48213C9665
7433-797
7433A797
7433A887
7433B797
7433B887
7433C797
7433C886
7433C887
8332-891
8433-896
8433A896
8433B896
8433C876
8433C8763
8433C87P
8433C896
8433D876
8433D8763
8433D879
8433D896
8433E776
8433E7763
8433E876
8433E8763

Some old models listed above require modifications before replacing. If unsure, contact us for more info.
