Coleman-Mach | 48204-066 | 15,000 BTU | 120V Air Conditioner | Textured White

  • Buy 3 for $907.19 each and save 5%
Introducing the Coleman-Mach Standard Height Air Conditioner, delivering 15,000 BTUs of cooling power tailored to your environment. With it's rugged Textured White finish, the 48204-066 belongs to the trustworthy Signature series of 120-volt rooftop ACs . Perfect for RVs, trailers, trains, booths or really anything with a 14X14 inch roof opening, ensuring a comfortable climate wherever you may roam.

The Signature Series

The Gold Standard for Coleman-Mach ACs

The signatures series embodies the innovation and quality that built the name Coleman-Mach over the last 55 years. Get superior cooling performance, the highest quality components, and more profile options than the competitors.


15,000 BTU/h Air Conditioner

Taking cooling power to the MAX by offering the highest cooling output available.

The world's most powerful RV air conditioner with the highest cooling output you can buy, and has an airflow so strong, it's a sure bet for ducted systems.


More Information
MSRP$1,303.39
Mfg Part #48204-066

Documentation

Installation, Operation & MaintenanceDOWNLOAD

Specifications

HeightStandard (13.8")
Weight (lbs)85
BTUs15,000
Heat Strip BTUs5,600
Electrical Rating115 VAC, 60Hz, 1 Phase
Full-Load Cooling Amps14.9
Full-Load Heating Amps16
Standard Running Watts1611
Running watts w/ heat strip1800
Air Delivery CFM320
ColorTextured White
Heat PumpNo
Power SaverNo
Condensate PumpNo
Soft StartNo
Model Number Changes

This unit is a replacement for the following models:

48204-666
48204-866
48204-876
48204B866
48204A866
48204A876
48204B866
48204C866
48204B876
48204C866
48204C876
48204C966
48214-876
48214A876
48214A876
48214B876
48214C876
48214C966
48254-866
48254-876
48254A866
48254A876
48254B866
48254B876
48254C866
48254C876
48254C966
48254C966
48264-876
48264A876
48264B876
48264C876
48264C966
7335-691
7335-6912
7335-692
7335-693
7335-697
7335-698
7335A691
7335A6912
7335A6913
7335A692
7335A6923
7335A696
7335A6963
7335A697
7335A6973
7335A698
7335A6983
7335B691
7335B6912
7335B6913
7335B6914
7335B6915
7335B6916
7335B692
7335B6923
7335B6924
7335B6926
7335B696
7335B6963
7335B6964
7335B6966
7335B697
7335B6973
7335B6974
7335B6976
7335B698
7335B6983
7335B6984
7335B6986
7335B891
7335B8912
7335B8913
7335B8914
7335B8915
7335B8916
7335B892
7335B8923
7335B8924
7335B8926
7335B896
7335B8963
7335B8964
7335B8966
7335B897
7335B8973
7335B8974
7335B8976
7335B898
7335B898
7335B8983
7335B8984
7335B8986
7335C691
7335C6912
7335C6913
7335C6914
7335C6915
7335C6916
7335C692
7335C6923
7335C6924
7335C6926
7335C696
7335C6963
7335C6964
7335c6966
7335C697
7335C6973
7335C6976
7335C698
7335C6983
7335C6984
7335C6986
7335C891
7335C891
7335C8912
7335C8913
7335C8914
7335C8915
7335C8915
7335C8916
7335C892
7335C8923
7335C8924
7335C8926
7335C896
7335C8963
7335C8964
7335C8966
7335c897
7335C8973
7335C8974
7335C8976
7335C898
7335C8983
7335C8984
7335C8986
7335C974
8335-6764
8335-8564
8335-871
8335-876
8335-891
8335-8912
8335-8914
8335-8915
8335-896
8335-8964
8335-8974
8335A896
8335B671
8335B6714
8335B676
8335B6762
8335B6763
8335B6764
8335B6765
8335B6766
8335B6767
8335B6769
8335B677
8335B6774
8335B6797
8335B67P
8335B67P3
8335B876
8335B891
8335B8914
8335B896
8335B8964
8335B8965
8335B8966
8335B8967
8335B897
8335B8974
8335B8997
8335C871
8335C8714
8335C876
8335C8763
8335C8764
8335C8765
8335C8766
8335C877
8335C8774
8335C8797
8335D671
8335D6714
8335D676
8335D6763
8335D6764
8335D6766
8335D677
8335D6774
8335D756
8335D7564
8335D7564
8335D771
8335D7714
8335D776
8335D7763
8335D7764
8335D7766
8335D777
8335D7774
8335D7794
8335D7796
8335D856
8335D8564
8335D866
8335D8664
8335D871
8335D8714
8335D876
8335D8763
8335D8764
8335D8766
8335D877
8335D8774
8335D8796
8335D8915
8335D896
8335D8964

Some old models listed above require modifications before replacing. If unsure, contact us for more info.
