47223-076 | Coleman Mach 8 13,500 BTU | Air Conditioner| Textured White | w/ Condensate Pump

BTUs: 13,500 Heat Pump: No Power Saver: No Condensate Pump: Yes Volt rating: 115VAC, 60Hz, 1 Phase Full-Load Cooling Amps: 13.4 Standard Running Watts: 1,395 Weight: 90Lbs Height: Low  (8.25")


Coleman Mach 8 13,500 BTU White Air Conditioner with Condensate Pump

The Mach8 has the lowest profile in the industry measuring in at 8 inches tall. Of course with the lower profile that means less drag and improved fuel efficiency. With two motors the Mach 8 delivers the same high BTUs of cool on both high and low speed operation. This unit has an industry exclusive molded one piece fiberglass base pan which provides excellent durability while reducing the weight.

  • Weighing in at 90 lbs, the MACH 8 is the LIGHTEST low profile unit madeBackward compatible with any Coleman Mach air conditioner, and installs easily from the roof for ducted top down mounted systems
  • Operates even at desert conditions of 125° F
  • Has the LARGEST BTU resistance heater of any RV air conditioner
  • Another Quality Coleman Mach air conditioner - 5,000,000 units and counting. All built in their Wichita, KS factory.
More Information
Mfg Part #47223-076


Installation, Operation & MaintenanceDOWNLOAD


HeightLow (8.25")
Weight (lbs)90
Heat Strip BTUs6,000
Electrical Rating115 VAC, 60Hz, 1 Phase
Full-Load Cooling Amps13.4
Standard Running Watts1,395
Running watts w/ heat strip1,748
Air Delivery CFM300
ColorTextured White
Heat PumpNo
Power SaverNo
Condensate PumpYes
Soft StartNo
