These thermostats are designed to operate all R.V. Products ceiling assemblies, which control the air conditioner 115 VAC circuits through 12 VDC relays. Wiring is required between the thermostat and the ceiling assembly. The thermostat wiring is field installed and must be considered before wall paneling and ceiling panels are in place. Wall thermostat controlled air conditioners are normally OEM (Original Equipment Manufacturer) installed. Wall thermostat controlled air conditioners may be installed for aftermarket applications, with additional considerations given to the thermostat wire routing. The 7330*335* and 7330*385* thermostat may also operate
any RV furnace 12 VDC control circuit not exceeding one amp. All thermostats are equipped with a replaceable 2 amp fuse located on the back of the thermostat body.
|Mfg Part #||7330G3351|
|Limited 2 Year AC Warranty||No|
|Operation and Maintenance||DOWNLOAD|
|Evaluating AC Performance||DOWNLOAD|
|Electrical Rating||115 VAC, 60Hz, 1 Phase|
