CHILLGRILL, NO CONTROL PKG for Center Ducted Installations 8430A6301

This replaces the older style 8330B6301 & 8430-6301

Exclusive DirectFlow Louver System provides cool air where you need it for personalized comfort in any RV!

• Open the specially designed Louvers to channel cool air straight down into the cabin.
• Close the louvers to divert cool air through your existing duct system.
• Exclusive EZReach Filter System provides quick access to the washable air filter.
• Slender profile provides plenty of overhead clearance.

For this application you will also need:

Control kit = 9530A751 (Heat Pump)

OR

Control kit = 9330C755 (Air Conidtioner)

Thermostat = 8530A3451

(Note:  The control box does not provide 12VDC for the thermostat, this will need to be supplied by the application.)

Add On Heat Kit:

For 47000 series use part number 47233-4551

For all but 47000 series use part number 9233A4551

Installation Instructions
