48203-069 | Coleman Mach 3+, 13,500 BTU AC, Black
- Buy 3 for $779.09 each and save 10%
The Mach 3 PLUS™ RV Air Conditioner's powerful compressor has a nominal cooling capacity of 13,500 BTU and a 320 CFM (cubic feet per minute) airflow.
MACH 3 PLUS AIR CONDITIONER
The Coleman®-Mach® 3 PLUS™ is one of the best RV air conditioning values available. It features a large evaporator and condenser coils with raised lance fins to help dissipate heat, has a solid 13,500 nominal BTU cooling capacity, and delivers 320 CFM (cubic feet per minute) airflow.
You can count on the Mach 3 PLUS™ for reliability. All-copper tubing and gas-flux brazed joints ensure durability and long life for your RV air conditioner. Add the optional Heater Assembly, and you.ll have 5,600 BTUs of heat for cool-weather outings.
- Motor is mounted directly to the bulkhead to prevent distortion of the angle of the blower wheel and to ensure a free turning action. This fixes the motor's position in relation to the blower.
- At 1/3 hp, the fan motor in the Mach 3 PLUS™ is the largest in the industry. It features a sealed shaft to protect against damage from the elements.
- Large evaporator and condenser coils with raised lance fins enhance the system's ability to dissipate heat.
- Start kit with start capacitors and PTCR device is standard equipment and makes starting easier under high temperature and humidity conditions.
- Optional Heater Assembly can be added to provide asource of warm air.
- Plastic drain pan eliminates corrosion.
- Corrosion-resistant, stainless steel truss head screws secure the shroud.
Product Literature
Installation Instructions
Operation & Maintenance
Data Sheet
Warranty Information
| MSRP | $1,068.69 |
|---|---|
| Mfg Part # | 48203-069 |
Documentation | |
| Installation, Operation & Maintenance | DOWNLOAD |
Specifications | |
| Height | Standard (13.8") |
| Weight (lbs) | 89 |
| BTUs | 13,500 |
| Heat Strip BTUs | 5,600 |
| Electrical Rating | 115 VAC, 60Hz, 1 Phase |
| Full-Load Cooling Amps | 15.3 |
| Full-Load Heating Amps | 16 |
| Standard Running Watts | 1,650 |
| Running watts w/ heat strip | 1,800 |
| Air Delivery CFM | 320 |
| Color | Textured Black |
| Heat Pump | No |
| Power Saver | No |
| Condensate Pump | No |
| Soft Start | No |
